MEGA Fuse Holder Bolt-Down Series High- Current Fuse Holder High-Current Circuit Protection 02981036ZXT Bolt-Down, M6 Slots X 15MM Long

MEGA Fuse Holder Bolt-Down Series High- Current Fuse Holder High-Current Circuit Protection 02981036ZXT Bolt-Down, M6 Slots X 15MM Long
MEGA Fuse Holder Bolt-Down Series High- Current Fuse Holder High-Current Circuit Protection 02981036ZXT Bolt-Down, M6 Slots X 15MM Long MEGA Fuse Holder Bolt-Down Series High- Current Fuse Holder High-Current Circuit Protection 02981036ZXT Bolt-Down, M6 Slots X 15MM Long MEGA Fuse Holder Bolt-Down Series High- Current Fuse Holder High-Current Circuit Protection 02981036ZXT Bolt-Down, M6 Slots X 15MM Long MEGA Fuse Holder Bolt-Down Series High- Current Fuse Holder High-Current Circuit Protection 02981036ZXT Bolt-Down, M6 Slots X 15MM Long

Grote Afbeelding :  MEGA Fuse Holder Bolt-Down Series High- Current Fuse Holder High-Current Circuit Protection 02981036ZXT Bolt-Down, M6 Slots X 15MM Long

Productdetails:
Plaats van herkomst: Chiana
Merknaam: littelfuse
Certificering: E71747
Modelnummer: MAGE
Betalen & Verzenden Algemene voorwaarden:
Min. bestelaantal: 500
Prijs: 3USD
Verpakking Details: 200x200x200cm
Betalingscondities: T/T
Levering vermogen: 300000
Contact

MEGA Fuse Holder Bolt-Down Series High- Current Fuse Holder High-Current Circuit Protection 02981036ZXT Bolt-Down, M6 Slots X 15MM Long

beschrijving
Markeren:

M6 - Sluitingen veiligheidsbeveiliging

,

Hoogstroomsluiting

,

Bolt Down-sluitinghouder

MEGA Fuse Holder Bolt-Down Series High- Current Fuse Holder High-Current Circuit Protection 02981036ZXT Bolt-Down, M6 Slots X 15MM Long 0


Description

Specifications
Agency Approval Shock: VS-005002/VS-005005
Current Rating Max: 500A
Fuse Type: MEGA (298)
Humidity: 97%±3% relative humidity
at 40°C±3C for 16 hrs
Flammibility Rating: UL-94 V-2
Ingress Protection: Dust Protection
Input Terminals: M8 Stud, M6 Stud
Mounting Method: Bolt-Down, M6 Slots / M6 Mounting Holes
Output Terminals: M8 Stud, M6 Stud
Recommended Torque: 8mm Hex Nut: 12-18 Nm (106-159 IN-LBS)
6mm Hex Nut: 8-14 Nm (71-124 IN-LBS)
Max Voltage Rating: 70VDC
Features & Benefits

Compatible with MEGA® bolt-down fuses (sold
separately unless indicated)
• Glass-filled thermoplastic body houses M8 or M6 input
and output terminals
• Interlocking pins on the sides of the fuse holder let you
connect additional MEGA® 298 Bolt-Down Series fuse
holders to create a multi-fuse block
• Base styles available with M6 mounting holes or
extended M6 x 15mm slots
• Included UL 94 rated protective cover has 6 available
locations for openings to accommodate various cable
entry needs (actual openings vary by part number)
• Configurations may also include a thermoplastic tether,
insulators, ratchet fasteners and/or mounting hardware
(see part numbers for details)
Dimensions





label:

Hoogstroomsluiting,

M6 - Sluitingen veiligheidsbeveiliging,

Bolt Down-sluitinghouder
